Walrus TQ400 - Remove Remaining Seal Components

Remove the 1
st
stage impeller. Remove the cap and spring.
Remove the rotary parts of mechanical seal. Remove ceramic parts from mech seal kit.
Remove the stationary part (rubber) of the
mechanical seal
9
11
10
8 7
