Walrus TQ400 - Install Pressure Tank and Stud Bolts

Tighten up the stud bolts. Install O-ring onto pressure tank.
(make sure the groove holding O-ring is clean)
Install the pressure tank
(arrow on top position)
Identify different sizes of stud bolts.
TQ400 M6x30mm – 2 pcs, M6x88mm x 4 pcs
Identify different sizes of stud bolts.
TQ800 M6x55mm – 2 pcs, M6x115mm x 4 pcs
Install shorter stud bolts on the red circled places.
14
13
16 15
18
17
