5
H25-991-2402B
H-25 Hydraulic End (with metallic pump head)
1
Piston Assembly includes cylinder, foot, valve plunger, O-
rings, spring retainer, and springs (50-59).
2
Cam Assembly includes cam, shaft, wobble plate, bearings,
and cups. It is only available as an assembly.
50 D25-019-3111 Spring, piston return ............................3
51 D25-042-1010 Retainer, piston return spring .............
3
52 D25-046-2110 O-ring, valve cylinder, Buna ................
9
53 D25-045-3110 Spring, sleeve valve ............................
3
K25-045-3110 Spring, sleeve valve, Kel-Cell .............
3
54 D25-044-1010 Valve Plunger ......................................
3
K25-044-1010 Valve Plunger, Kel-Cell .......................
3
55 D25-043-1010 Cylinder, valve .....................................
3
K25-043-1010 Cylinder, valve, Kel-Cell ......................
3
56 D25-034-2110 O-ring, Buna ........................................
6
57 D25-041-1010 Washer, ball retainer ...........................
3
58 D25-015-3010 Ball, 1/4” ...........................................12
59 D25-014-1209 Piston, with foot and retainer ..............3
D25-014-1210 Piston Assembly
1
..............................–
K25-014-1210 Piston Assembly, Kel-Cell
1
...............–
60 D25-075-2110 O-ring, bearing adjusting plate, Buna .
1
61 D25-012-1010 Bearing Adjusting Plate
.......................1
62 H25-007-1210 (X) Cam Assembly, 20 GPM
@ 1050 RPM
2
....................................1
H25-007-1212 (I) Cam Assembly, 12 GPM
@ 1150 RPM
2
....................................1
H25-007-1213 (S) Cam Assembly, 16 GPM
@ 1150 RPM
2
....................................1
H25-007-1214 (E)Cam Assembly, 20 GPM
@ 1150 RPM
2
....................................1
63 D25-085-2210 Key, shaft ............................................
1
64 H25-031-2112 Seal, Buna, 1-1/8” ................................
2
65 H25-037-2110 O-ring, pump housing, Buna,
Ser. No. 100403 & above ....................
1
– D25-111-2400 Label, caution ......................................
1
Ref. Quantity/
No. Part Number Description Pump
