1.3 Unit Design
4 Rotating direction monitor G
(SC 730 only)
5 Calcification alarm G
G This symbol means: not available on all models (special equipment, model versions).
1 Power cable
2 Tap water supply connection
3 Swivel castor with locking brake
4 Cleaning-agent metering unit
5 High-pressure hose connection
6 Cleaning agent tank
7 Spray gun
8 Spray-lance storage slot
9 Exhaust outlet
10 SuperClean H-I/HL-I Nozzle
11 Control panel
12 Fuel tank
13 High-pressure hose
1 Unit switch
2 Temperature control
3 Fuel shortage alarm G
