1.4 Technical data
SC 702
SC 702SC 702
SC 702 SC 720
SC 720SC 720
SC 720 SC 730
SC 730SC 730
SC 730
Volume flow l/min 8,3-5,8 9,2-4,7 10,2-4,7
Working pressure bar 105-50 130-25 140-25
Permissible gauge pressure bar 200 200 200
Permissible temperature °C 80/99 80/140 75/140
Max. supply temperature °C30 30 30
Max. water feed pressure bar 10 10 10
Ave. fuel consumption ( 50 °C) kg/h 2,7 2,8 3,0
Voltage V 230/1-ph. 230/1-ph. 400/3-ph.
Frequency Hz 50 50 50
Electrical connection kW 2,6 3,6 4,3
Fuse A 16 16 16
Protection class I I I
Protection type IP 45 45 45
Water content of heating coil l 2,65 2,65 2,65
Fuel tank capacity l 11,5 11,5 11,5
Additive tank capacity l 5,5 5,5 5,5
Sound level at 1 m distance dB(A) 83,2 83,0 82,7
Length mm 1020 1020 1020
Width mm 590 590 590
Height mm 600 600 600
Weight kg 77 79 79
,t=
1.5 Unit operation
Main subassembly I - Drive motor with high-pressure pump, safety control block with automatic pressure
switch-off feature, flow monitor and high-pressure blower burner with fuel pump
• The float valve controls the water supply.
• The high-pressure pump sucks water out of the water box and transports the water under pressure to
the high-pressure nozzle.
• The safety control block with automatic pressure switch-off feature and safety valve ensures pressure
monitoring and limitation.
• The automatic calcification alarm
G
meters the anti-calcification concentrate.
• The metering valve is used to add cleaning and care agents and to rinse the intake system.
Main subassembly II - Heat exchanger with temperature monitor
• The heat exchanger with high-pressure blower burner produces hot water.
• The fuel is supplied via a fuel pump driven by the pump motor.
• The thermostat monitors the working temperature.
• The flow monitor switches the oil burner off in the case of a water shortage.
• The thermal fuse acts as an additional safety element against overheating.
Water quantity, pressure and temperature are steplessly adjustable.
