WarmFlow Air Source A-Series User Manual

Page 42
F13
Mute Mode
Speed
*
600r
Set fan speed when in mute (reduced fan
speed) mode
F14
DC/EC Fan
Rated Speed
*
600r
Rated fan speed
F15
Fan Motor Type
*
1/2
Type of fan motor (0 for High, 1 for DC
single fan, 2 for DC double fan)
* Indicates that this parameter is not adjustable
Table 12 System Parameters
Parameter
Name
Range
Default
Description
H01
Auto Start
*
1
After a power cut, the unit will remain off
(0) or return to the last mode (1)
H02
Master/Slave
Unit
0/1
0
Sets the unit as the master (0) or slave
(1) if more than 1 unit is installed
H03
Temperature Unit
*
0
Sets the temperature unit to be
displayed, 0 for °C, 1 for °F
H04
4-Way Valve
Polarity
*
0
Sets the operation of the 4-way valve, 0
for on with heating, 1 for off with heating
H05
3-Way Valve
Polarity
0/1
0
Sets the operation of the 3-way valve, 0
for on with DHW, 1 for on with heating
H06
Frequency
Control P Value
*
5
The P value of the PID output control
functionality
H07
Frequency
Control I Value
*
1
The I value of the PID output control
functionality
H08
Frequency
Control D Value
*
5
The D value of the PID output control
functionality
H09
Min Frequency
*
30Hz
The minimum frequency which the
compressor will operate
H10
Max Frequency
*
30Hz
The maximum frequency which the
compressor will operate
H11
Model
Selection
*
0
Compressor type selection
H12
Manual
Frequency
*
0Hz
If set (greater than 0) the compressor will
run constantly at this speed when on
H13
PFC Function
Enable
*
1
Disables (0) or enables (1) the power
factor correction functionality
