2.2.2 Fan Stat (Cover Removed)
2.2.3 Air Heater Control Panel
Fan Override Button (White)
Keep Pulled Out
High Limit Stat Setting Peg (100°C)
Fan on Setting Peg (40°C)
Fan Off Setting Peg (20°C)
High Limit Reset Button (Red)
Overload Relay
Reset Button (Red)
Contactor
5 Pin Mains In Plug
Room Stat
5 Amp Fuse
Burner Cable
3 Position
Rocket Switch
Burner on
Lamp
2 Position
Rocker Switch
Clock
