WarmFlow WAH 100 - 3 General Data; Technical Data

3.0 General Data
3.1 Technical Data
WAH MODEL 100/150 200/300 500/600
Output Range kW 29.3-44.0 58.6-88.0 146.5-175.8
Nominal Heat kW 52.4 102.3 206.9
Input (max) Btu 178,800 349,000 705,900
Nominal Heat kW 44.0 88.0 175.8
Output (max) Btu 150,000 300,000 600,000
Nominal combustion efficiency gross % 84 86 85
Burner Riello RDB 2 G10 G20s
Head LD3 A G10 G20s
Flue Dia mm 127 152 203
Flue Dia in 5 6 8
Exit Flue Gas Mass Flow Kg/h
Co2 % 11.0 11.0 11.0
Smoke Bacarach 0-1 0-1 0-1 0-1
NFGT °C 225 185 195
Nozzle Danfoss or Delevan
(Kerosine) 1.25 x 60°S 2.5 x 60°S—
Pump Bar 10 9 —
Pressure psi 145 130 —
Nozzle Danfoss or Delevan
(Gas Oil) 1.0 x 60°S 2.0 x 60°S 4.0 x 60°S
Pump Bar 13 12.5 13.0
Pressure psi 190 180 190
Approx Fuel L/h 5.2 10.1 20.4
Flow Rate Gal/h 1.14 2.22 4.49
Fan Motor kW 0.37 1.1 2.2
Motor Speed rpm 1,440 1,440 1,440
Running Current Amps 1.8 4.8 5.6
Electrical Supply at 50hz Volts 230 ± 6% 1PH 230 ± 6% 1PH 400 ± 6% 1PH
Fuse Rating (per phase) Amps 5 8 16
Temp Rise °C40 4240
Inlet Air Flow @ 15 C CFM 1,590 2,755 7,355
M
3
/h 2,700 4,680 12,500
No of Discharge Hoods 2 2 4
Fan Speed (Nominal) rpm 650 900 925
Weight (including burner) Kg 195 360 680
Page 7
