WARRIOR 150 - Page 38

38
Recovery
REF
PART NO. DESCRIPTION NOTES:
1
545-100 Dump Valve, 1 1/2”
2
585-210 Clear Cover, 6” C/W Ring
3
590-020 PVC ELB 1 1/2” 90, S x FIPT
4
475-125 Gasket 6” Access Cover Clear
5
400-116 Locknut, 5/16 x18 Nylon SS
6
405-026 Bolt, 1/4 x 1-1/2 Zinc
7
405-615 CS, 1/4 x 1/2 SS (Hex HD)
8
410-125 SMS, 8 x 5/8 Pan Rob SS
9
415-125 FW, 1/4 SS
10
415-128 FW, 5/16 SS
11
415-305 FNDW, 1/4 SS
12
455-070 Wheel, 3”
13
355-230 Vac Bolt Spacer 3/8 x 1-1/8
14
597-015 Adpt (RM) 30 Degree, Float 2”
15
495-320 Rec tank, Warrior Blue
16
597-062 Float Screen Cage 2”
17
465-082 BRKT, Cord Mount
18
590-419 PVC Hose Barb, 2” HB x 1 1/2” MPT
19
410-265 MS, 5/16 x 2-1/2 Pan Phil SS
20
595-010 ABS Pipe, 2”
21
415-420 Machined Washer 1 7/8
22
465-066 Brace, Warrior Tank (W/O Heat Model)
