WARRIOR 150 - Page 42

42
Vacuum, 2-Stage, 3-Stage
REF
PART NO. DESCRIPTION NOTES:
1
400-135 Locknut, 1/4 x 20 Nylon Zinc
2
410-221 MS, 10-32 1-1/2 RH Soc
3
425-015 Clamp, #28
4
415-120 FW, 1/4 Zinc
5
415-115 FW, #10 SS
6
355-220 Manifold, Dual Vacuum
7
475-072 Gasket, Vacuum Manifold
8
405-065 6” Bolt
9
410-136 SMS, 8 x 3/4
10
570-020 Vac Hose 2”
11A
355-300 Vac , 2-Stage
11B
355-305 Vac , 3-Stage
12A
355-310 Housing, Vac Motor, 2-Stage
12B
355-315 Housing, Vac Motor, 3-Stage
