WARRIOR 45SPS12 - SPECIFICATION

15
SPECIFICATION
Rated line pull
4500 lbs (2041 kgs)
Motor: permanent magnet
12V:Input: 2.4 kW/ 3.2hp; Output: 1.0 kW/ 1.3hp
24V:Input: 2.9 kW / 3.9hp; Output: 1.3kW / 1.7hp
Gear reduction ratio
172:1
Cable (Dia.× L)
Ø1/4"×47.6' (Ø 6.4mm×14.5m)
Drum size (Dia.× L)
Ø1.77"×3.7" (Ø 45mm×93 mm)
Mounting bolt pattern
5.1"×3.78" ( 129mm×96 mm) 4-M8
Overall dimensions
(L×W×H)
14.9"×5.0"×7.9"
378mm ×126mm ×200mm
Net weight
Ibs(kg)
28.7
13.0
Pull, Speed, Amperes, Volts (First layer):
Line Pull
Line Speed ft/min (m/min)
Current A
Ibs (kgs)
12V DC
24V DC
12V DC
24V DC
0
11.6(3.6)
12.5(3.8)
20
15
1500(680)
9.2(2.8)
10.5(3.2)
70
40
2500(1134)
7.8 (2.4)
8.5(2.6)
100
65
3500(1588)
6.6(2.0)
7.2(2.2)
140
80
4500(2041)
4.9(1.5)
5.9(1.8)
200
130
Line Pull And Rope Capacity In Layer
Layer of cable
Rated line pull lbs (kgs)
Total rope on the drum ft (m)
1
4500(2041)
7.6(2.3)
2
3642(1652)
17.0(5.2)
3
3060(1388)
27.0(8.3)
4
2638(1196)
38.6(11.8)
5
2254(1023)
47.6(14.5)
