Page 12 For technical questions, please call 1-888-866-5797. Item 58089
Specifications
Electrical Rating 120VAC / 60Hz / 4.3A
Motor No Load Speed 12,000 RPM
Max. Accessory Diameter
(sold separately)
4-1/2″ (115 mm)
Max. Accessory Thickness 1/4″
Arbor Hole Diameter 7/8″
Spindle Thread 5/8″ x 11 TPI
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch of the tool off and unplug the tool from its electrical
outlet before assembling or making any adjustments to the tool.
Note: For additional information regarding the parts listed in the following pages,
refer to the Assembly Diagram near the end of this manual.
Assembly
Installing the Wheel Guard
TO PREVENT SERIOUS INJURY: Do not operate this tool without the Wheel Guard properly installed.
1. Loosen the Wheel Guard Bolt.
2. Slide the collar of the Wheel Guard
over the rim of the Gear Housing.
3. Rotate the Wheel Guard as needed to
shield you during the planned work.
4. Tighten the Wheel Guard Bolt securely.
5. Check the Wheel Guard to ensure
it is firmly in place. Adjust if
necessary before proceeding.
Installing the Auxiliary Handle
TO PREVENT SERIOUS INJURY:
Do not operate this tool with one hand only or without the Auxiliary Handle properly installed.
1. The Auxiliary Handle may be installed
in one of two positions, on either
side of the Gear Housing.
2. Screw the threaded end of the
Auxiliary Handle into the selected position.
Tighten securely before beginning work.
SAFETY OPERATION MAINTENANCESETUP
