Page 14 For technical questions, please call 1-888-866-5797. Item 58089
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Tool Set Up
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch of the tool off and unplug the tool from its
electrical outlet before installing accessories.
Installing a Non-threaded Grinding Wheel
1. The Grinding Wheel (sold separately) MUST be:
• rated to at least 12,000 RPM
• no larger than 4-1/2″ (115 mm) in diameter
• fitted with a 7/8″ round arbor hole
• 1/4″ thick or less
• suitable for surface grinding, not edge grinding
• dry and clean
• proven undamaged by inspection.
2. Press in and hold the Spindle Lock Button
to prevent the Spindle from turning.
3. Remove the Outer Flange. Keep the
Inner Flange in position on the Spindle.
4. Closely inspect the Grinding Wheel before mounting.
WARNING! TO PREVENT SERIOUS INJURY:
Do not use worn or damaged wheels.
5. Place Grinding Wheel on Spindle.
Note: The Outer Flange has a step for improved
stability with thick accessories. Keep this step
on the inside for thick accessories. To allow
proper clamping for thin accessories, flip Outer
Flange so this step is on the outside.
6. Thread the Outer Flange onto the Spindle.
Wrench tighten only enough so that the wheel is
securely held on the spindle.
WARNING: To prevent serious injury,
do not overtighten flange. Overtightening can
damage the wheel, causing wheel failure.
Installing a Threaded Accessory
TO PREVENT INJURY: Wear heavy-duty work gloves when handling wire wheels and brushes.
These accessories are sharp and can cause injury.
1. The accessory MUST be:
• rated to at least 12,000 RPM
• no larger than 4-1/2″ (115 mm) in diameter
• fitted with a threaded opening of 5/8″ x 11 TPI
• undamaged
• a sanding disc and backing pad,
a sanding flap disc, a wire wheel or
a wire cup brush (accessories not included).
2. Press in and hold the Spindle Lock Button
to prevent the Spindle from turning.
3. Remove the Outer Flange and the
Inner Flange and keep in a safe place.
4. Thread disc accessory firmly onto the Spindle.
Wrench tighten onto the Spindle.
SAFETY OPERATION MAINTENANCESETUP
