WARRIOR DIG1500 - Page 21

9. SPECIFICATION
MODEL
1200i
1500i
1800i
GENERATOR
Type
Inverter Generator
AC Voltage
50Hz
100, 230V, 240V
60Hz
100, 120V, 240V
Max. Output
1.2 kVA
1.5 kVA
1.8 kVA
Rated Output
1.0 kVA
1.2 kVA
1.5 kVA
Power Factor
1.0
DC Output
12V / 4.0A
ENGINE
Model
XY147F
Type
Air-cooled, 4 cycle, OHC, Gasoline Engine
Bore Stroke mm x mm
47 × 41.5
Displacement
72 cc
Max. Output
2.1KW / 5500rpm
Fuel
Regular Automobile Gasoline
Fuel tank Capacity
3.6 litres
Rated Continuous Operation
4.3 hr.
4.3 hr.
4.0 hr.
Lubricating oil
SAE 10W30
Lubricating oil Capacity
0.60 litres
Starting System
Recoil Starter
Ignition system
C.D.I.
Spark Plug: Type
A7RTC or CR5HSB (NGK)
DIMENSION
Net dimension L × W × H
492 × 262 × 406
Overall dimension L × W × H
525 × 295 × 440
Net Weight
18.5 Kg
18.5 Kg
18.5 Kg
Dry Weight
20.5Kg
20.5Kg
20.5Kg
• Specifications subject to change without prior notice.
