WARRIOR SAMURAI S8000 - Winch Parts List（S9500 Sd

20
WINCH PARTS LIST (S9500SD)
No.
Part #
Qty
Description
Remark
1
950100
1
Motor Assembly
2
95SD0001
6
Cap Screw M10 x 35
3
95SD0002
6
Lock Washer Φ10
4
95SD0003
6
Think Flat Washer Φ10
5
95SD0004
6
Hex Flange Nut M10
6
1200200
1
Break / Shaft Assembly
7
1200005
2
Bushing—Drum
8
95SD0006
2
Tie Bar
9
95SD0007
1
Screw M8 x 10
10
95SD0008
4
Think Flat Washer Φ8
11
95SD0009
4
Cap Screw M8 x 30
12
95SD0300
1
Drum Assembly
13
95SD0010
8
Screw M5 x18
14
95SD0011
8
Lock Washer Φ5
15
1200012
1
End Bearing
16
95SD0013
1
Gasket
17
95SD0014
1
Gear—Ring
18
95SD0400
1
Gear Carrier Assembly（Input）
19
95SD0500
1
Gear Carrier Assembly（Intermediate）
20
95SD0600
1
Gear Carrier Assembly（Output）
21
95SD0015
1
Gear—Input Sun
22
95SD0016
1
Trust Washer
23
95SD0017
1
Gear—Housing
24
95SD0018
1
Clutch Screw
25
95SD0019
1
Ring Seals
26
95SD0020
1
Clutch Cover
27
1200021
1
Clutch
28
95SDRS
1
Remote Control Switch（R8）
29
95SD0800
1
Cable Assembly
30
95SDWRS
1
Wireless Remote Control Switch
31
95SD0900
1
Roller Fairlead
32
95SD0022
1
Mounting Play
33
95SD0023
1
Connecting Piece
34
95SD0024
1
Connecting Piece
35
95SD1300
1
Wireless Switch Receiver
36
1201400
1
Relay with Screw Assembly
37
951500
1
Cover with Screw Assembly
38
95SD0025
1
Connecting Piece
39
1200026
4
Connecting Block
40
95SD0027
2
Connecting Rod Sets
41
95SD0028
2
Ring Seals
42
95SD1600
1
Control Assembly
43
95SD0029
1
Six angle bar
