I/O modules
16
6266
17
6265











24V
230V
• Connection8maybeconnectedifthereistobeapauseinthewash
program,e.g.whiledetergentisbeingdosed.
 Thegureshowsanexampleofengaginga24Vpausesignal.Thewash
programwillpauseforaslongasthepausesignalremainsactive(high).
• Ifconnection7isconnected,anerrormessagewillbeshowninthe
displayifanyofthechemicaltanksareempty.However,thewashpro-
gramwillcontinue.
 Thegureshowsanexampleofengaginganormalopencontact.
