WASD V3 - Macro Programming; Macro Recording Process; Moving Pgm or Fn Keys; Macro Programming Limitations

Macro Programming
Action
LED State
LED1 = Caps Lock, LED2 = Scroll Lock
1. Enable Pgm Key and Fn Key
LED1+2 = Normal function
2. Press Pgm + Fn to enter Macro Programming
LED1 = Green
3. Press target key or key combo
LED1 = Red
4. Input Programming
LED2 = Flash red on input
5. Press Pgm to save macro
LED1+2 = Flash green 2 times
6. Go back to Step 3 or press Pgm + Fn to exit Macro Programming
LED1+2= back to normal function
Move Pgm or Fn Keys
1. Enable Pgm Key and Fn Key
LED1+2 = Normal function
2. Press Pgm + Fn to enter relocation Programming
LED1 = Green
3. Press and hold Pgm or Fn key for 5 seconds
LED1 = Red
LED2 = Flash red, then solid green after 5 seconds
4. Input destination key
LED1 = Solid green
LED2 = Flash Green
5. Go back to Step 3 or press Pgm + Fn to exit relocation Programming
LED1+2= back to normal function
Macro Programming Limitations
1. Each layer can record up to 25 macros
2. Each macro can hold up to 32 keys
3. Target can be single key or a combo up to 3 keys
(ie: “W”, “Fn + W”, “Fn + Ctrl + W”)
4. Combo keys will be “released” before macro is sent. Avoid using keys such as Alt and
OS/Win as those keys will trigger an action before sending the macro
5. Layer switching function cannot be moved or programmed
Clear Macro Programming for Layer
Press and hold the target layer key for 10 seconds. LED’s will flash green indicating that layer has
been reset. (For example, hold Fn + m to reset Layer 1)
