Page 3
Understanding the Wired Transmitter
Installation
Installing the Doorbell Transmitter
Choose a location that's nowhere near a heat or water
source, and that won't be hit when opening the door.
1. Remove the silicone stopper from the top of the
transmitter.
2. Use a pin to press the notch and remove the back cover.
1
2
3
1. Wired transmitter
2. Spade connector wire
3. AC power adapter
connector
