Water Tec CP - The Wall Mount F.G. RO (WM)

Water Tec Int’l. Inc. Version 02A
11
6. Waste Needle Valve
7. Module – R.O. membrane and Housing
8. Powder Coated Steel Frame
9. Electrical Control Box (not shown)
10. Rotary Vane Pump and Motor (not shown)
GENERAL SYSTEMS DIAGRAM (WM)
1. Incoming Feed Water
5. Rotary Vane Pump
(Pre-Filter supplied, but not shown)
2. Electrical Control Box
2a:On/Off Switch
2b:Power On Indicator
1
2
2a 2b 2c 2d
3
4
5
6
12
8
9 10 11
7
* This photo is
shown with
options.
