Water Tec CP - Page 12

Water Tec Int’l. Inc. Version 02A
12
2c:Low Pressure Indicator
2d:5amp Fuse
3. System Pressure Gauge
6. Recycle Needle Valve
7. Solenoid Valve
8. Module – R.O. Membrane & Housing
9. Permeate Flow Meter
10. Concentrate Flow Meter
11. Fiberglass Panel/Frame
12. Pressure Tank (Optional)
4. Motor
GENERAL SYSTEM DIAGRAM (WMXL)
1. Incoming Feed Water
2. Electrical Control Box
2a. On/Off Switch
2b. Power On Indicator
2c. Low Pressure Indicator
2d. 5amp Fuse
2e. OPTION: Digital TDS Meter
3. Control Panel
3a. Permeate Flow Meter
3b. Concentrate Flow Meter
3c. Incoming Pressure Gauge
3d. System Pressure Gauge
3e. Recycle Control Valve
3f. Waste Control Valve
4. Single Cartridge Pre-Filter
2b 2c 2d 2e 2a 3a 3b 3c 3d 3e 3f
3
1
4
2
5
5a
6
7
