5. High Pressure Multistage Pump
5a. Solenoid Valve
6. Module-R.O. Membrane & Housing
7. Powder Coated Steel Frame
GENERAL SYSTEM DIAGRAM (VXL)
1&2. Incoming Feed Water and
Pre-filter (not shown)
3. Electrical Control Box
3a. On/Off Switch
3b. Power On Indicator
3c. Low Pressure Indicator
3d. 5amp Fuse
4. High Pressure Pump and Solenoid
5. Control Panel
5a. Incoming Pressure Gauge
5b. System Pressure Gauge
5c. Waste Control Valve
5d. Recycle Control Valve
5e. Concentrate Flow Meter
5f. Permeate Flow Meter
3
3a 3b 3c 3d
4
5a
5b
5c
5d
5e
5f
6
7
