Watts Dead Level Series User Manual

4
6A Connecting Center Sections
6A.1 Layout sections as shown below.
6A.2 Cut the CA-M adapter to fit the bottom depth of the channel section.
6A.3 Cut the top section of the CA-M to fit the depth of the top of the channels.
CA-M
After Cutting
to Depth of
Channel
CA-M
Cut to Fit
Depth of
Channel
Top Section of
CA-M
Cut to Fit
Depth of Top
Section of
Channel
Top Section of
CA-M
After Cutting to
Depth of Top of
Channel
*Note: The CA-M is equipped with distinct grooves for ease in cutting to the correct size.
Top of CA-M w/Grooves for Cutting
Sides of CA-M w/Grooves for Cutting
