Kit Components
The retrofit connection kit for installing and activating the flood
sensor includes the items shown below. If any item is missing,
speak with your account representative about ordering
code 88009428.
A. Activation module with 8' conductor cable and ground wire
B. Cellular Gateway with mounting tabs and screws
C. 24V Power adapter
D. Small sensor for valve sizes ¾" to 1"; large sensor,
valve sizes 1¼" to 2"
NOTICE
When installing an air gap, attach the air gap brackets directly
onto the flood sensor.
Requirements
• #2 Phillips screwdriver
• Wire stripper
• Suitable location within 8 feet of the flood sensor for
mounting the Cellular Gateway on a wall or structur
e
• 120VAC, 60Hz, GFI-protected electrical outlet
• Ground wire running from the Cellular Gateway to the
gr
ound point
• Cellular network connection
• Internet browser
