CHAPTER 9  CLICK 110 91
Outstation Mode
Also on this switch is the outstation mode. is is congured on the third DIP switch, la-
beled S3, using switch 6 (S3:6).
Note
This parameter can only be changed using the DIP switches.
e Click 110 can be used with two brands of outstations, Peek and Siemens. Because of
dierences in the way these two operate, you need to use switch 6 on the S3 DIP switch to
tell the Click 110 with which outstation it is going to be used.
If S3:6 is o (down), the Click 110 is set to work with a Peek brand outstation. If S3:6 is on
(up), the Click 110 is set to work with a Siemens brand outstation.
S3: Outstation Mode
6 State
O Peek
On Siemens
Table 9.5 – DIP Switch Outstation Mode Settings
Note
In Peek mode the Isolated fault output channels are N/C; in Siemens mode they are
N/O. The Master Fault output relay is also opposite when switching between the two
modes. Refer to the pinout table earlier in this chapter for more information.
Because Outstation mode can only be changed using the DIP switches (though it can be
viewed elsewhere), there is no option for selecting Hardware or Soware conguration modes.
Fault Latch
e last option that can be congured on the DIP switches is fault latching. is is cong-
ured on the third DIP switch, labeled S3, using switch 8 (S3:8).
Note
This parameter can only be changed using the DIP switches.
