Wavetronix Click 65 Series - Chapter 2 Quick Start Guide; Installation 7 • Front Panel Configuration 8 • Sensor Configuration 8 • Web Configuration

In this chapter
 Installation
 Front Panel Configuration
 Sensor Configuration
 Web Configuration
1
ere are four main steps for installing and using the Click 650 and 656 (or 65x, as we’ll
oen refer to them in this guide): installation, front panel conguration, sensor congura-
tion, and web conguration.
Installation
1 Place the Click 65x in the trac cabinet. ey are designed to be shelf-mounted. An
optional mounting accessory provides U-channel mounting brackets for wall attach-
ment; there is also a 19-inch rack shelf option available from Wavetronix.
2 Connect one to six sensors to the connectors on the back of the Click 65x. Make note
of which sensor port is used for each sensor.
3 Power on the unit using the switch at back. e OLED panel should activate and dis-
play the initial loading screen.
4 Power on all connected sensors by toggling the appropriate switches on the front of the
Click 65x. Each switch has a corresponding green LED to mark whether the sensor is
powered or not.
5 Connect communication cables (Ethernet, SDLC, and/or contact closure RS-485 out-
puts) into their respective ports on the front of the device.
Quick Start Guide 1
