Address Description [ unite] Value
4121 Water temperature (WTC 43/44-input) [0.1 °C] 0..1000
4122 1. DWP resistance [kohm] 100..20000
4123 2. DWP resistance [kohm] 100..20000
4124 3. DWP resistance [kohm] 100..20000
4125 4. DWP resistance [kohm] 100..20000
4126 5. DWP resistance [kohm] 100..20000
4127 Relative humidity [0.1%] 10..1000
4128 RH temperature [0.1 °C] 0..500
4132 PI output [0.1%] 0..1000
4133 Dew point [0.1 °C] 0..500
4134 Type of unit (DIP4) 0..15
4136 TH1 measured temperature [0.1 °C] 0..500
4137 TH1 humidity [0.1 %] 0..1000
4138 TH1 calculated dew point [0.1 °C] 0..500
4139 TH1 pot meter [0.1 °C, +/- sign] -max..+max
4140 TH1 DWP resistance [kohm] 0..20000
4141 TH1 brightness [lux] 100..1000
4142 TH2 measured temperature [0.1 °C] 0..500
4143 TH2 humidity [0.1 %] 0..1000
4144 TH2 calculated dew point [0.1 °C] 0..500
4145 TH2 pot meter [0.1 °C, +/- sign] -max..+max
4146 TH2 DWP resistance [kohm] 0..20000
4135
Status of control
0: Initialization (onl after turn on)
1: Heating
2: Cooling
3: Heating / Cooling changeover
0..3
4147 TH2 brightness [lux] 100..1000
4148 TH3 measured temperature [0.1 °C] 0..500
4149 TH3 humidity [0.1 %] 0..1000
4150 TH3 calculated dew point [0.1 °C] 0..500
4151 TH3 pot meter [0.1 °C, +/- sign] -max..+max
4152 TH3 DWP resistance [kohm] 0..20000
4153 TH3 brightness [lux] 100..1000
