Way Train 250S - Feartures; Noise; Safety Device; Specification

G. NOISE:
A weighted sound pressure level : 80 dB.
H. SAFETY DEVICE:
Interlock switch on cutting area as soon as the cover of cutting area is open,
machine will stop at once witch the function of this switch. Do not remove this
switch from machine for any reason, and check its function frequently.
3.SPECIFICATION
MOTOR 2HP
Saw Blade Speed Variable Speed
60Hz 98 ~ 394FPM
Blade Size(mm) 27x0.9x3352
Dimension L x W x H (mm) 1880x720x1100
N.W / G.W (kgs) 390 / 430
Packing
Measurement
1.930x864x1.257
○(mm/inch)
254mm / 10 “
0°
□(mm/inch)
76x458mm / 3“x18“
○(mm/inch)
254mm / 10 “
+/- 45°
□(mm/inch)
254x280mm / 10“x11“
○(mm/inch)
204mm / 8“
Cutting
Capacity
- 60°
□(mm/inch)
127x204mm / 5“x8“
4.FEARTURES:
1. This machine is useful for cutting normal steel, steel pipe, and provides cutting
angle at + 60°and -45°by the swivel head.
2. A tooth selection label Ms provided on the machine for cutting reference.
3. Variable speed control gives convenient selection of speeds.
4. Hydraulic cylinder controls feeding volume and provides stable cutting.
5. Easy sliding the working table back and forth by loosing and fixing only two
bolts.
6. Quick positioning vise for clamping all sizes of work piece.
7. Chip pan underneath the working table prevents coolant fluid leaking and keep
floor dry.
