Wayfair CORNER BOOKCASE - Assembly Instructions; Step 1: Attach Right Frame; Step 2: Attach Left Frame

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 4
Figure 1
Unpack and lay parts on a
clean, padded surface like a
carpet or blanket. Check that
you have all parts indicated on
the front page.
Step 1
Insert Nuts (2) into Shelf
Panels (C) and Bottom Panel
(D). Rotate Nuts (2) to
accommodate Bolts (1).
Then attach Right Frame (A)
to Shelf Panels (C) and
Bottom Panel (D) using Bolts
(1) and Nuts (2). Tighten Bolts
(1) with Allen Wrench (4).
Figure 2
Step 2
Insert Nuts (2) into Shelf Panels
(C) and Bottom Panel (D) on
pre-assembled unit in Figure 1
Rotate Nuts (2) to
accommodate Bolts (1).
Then attach Left Frame (B) to
Shelf Panels (C) and Bottom
Panel (D) on pre-assembled
unit in Figure 1 by inserting
Wooden Dowels (5). Connect
Bolts (1) to Nuts (2). Tighten
Bolts (1) with Allen Wrench (4).
Assembly Instructions
CORNER BOOKCASE
