Wayfair CORNER BOOKCASE - Step 5: Attach Wall Brackets; Step 6: Mount Brackets to Wall

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 6
Figure 5
Step 5
Attach Brackets (8) to Right
Frame (A) and Left Frame (B)
on pre-assembled unit in Figure
4 using Screws (11). Tighten
Screws (11) with a Phillips
screwdriver.
Figure 6
Step 6
Mark two desired locations on
the wall and then drill two 3/16"
holes into the wall.
Insert Anchors (7) into the two
holes in wall as shown in Figure
6. You will need a hammer to
set Anchors (7).
Attach Brackets (8) to the wall
using Screws (10).
Tighten Screws (10) with a
Philips screwdriver.
