5
June 2001 Part No. 920525 Rev A
At this point, pressing of NEXT will advance the sub-function to the next sub-function, incrementing the
value of N by (.01). For example, to access F3.02, press NEXT. The unit price display will show 3.02,
press NEXT. The desired sub-function depends on the dispenser type. Table 2-1 shows the values of N
that define the desired sub-functions for the dispensers shown. Once the desired sub-function is accessed,
the price display will show “– – – – – – and the volume display will show the current value of the unit
price. The following procedure must then be followed to set the unit price.
Changing the Value of the Unit Price
Type in the new unit price with at least three digits for three money display digits to be shown after the
decimal point.
*
For example, to set the new unit price to $1.50, type in 1500. Type in 1509 for $1.509
unit price.
1. Press #. The volume display will show the unit price with the correct number of digits after the decimal point.
Again, for the example above, the volume display will show 1.500.
2. Press NEXT to input the next unit price, and repeat steps 1 and 2. Continue until all the unit prices are input
and Save the unit prices as per the following procedure: Note that while inputting the unit prices, the unit price
display continues to show the sub-function and not the unit price itself.
Saving the New Unit Prices
1. Press ENTER. The price display will show “– , the volume display will be blank and the unit price display
will show the last sub-function accessed.
2. Press 00 (to access F00)
3. Press ENTER. The unit price should now display F00, the price display will show “– and the volume dis-
play will be blank.
4. Press ENTER and the volume display will show a 1.
5. Press UP twice to change the value in the volume display from 1 to 3
6. Press ENTER. The volume display should show a 3.
7. Press ENTER. CHANGE STORED should appear on the display momentarily. The display should return to normal
in a few seconds. When it does, the unit price displays should show the new prices. If they do not show the desired
unit prices, access the appropriate sub-function to make sure that the unit price data is correct.
TABLE 2-1 Hose Positions Defined by Values of N.
* This is the default mode. The number of digits after the decimal points is set in function F14.02.
DISPENSER
TYPE
N=7 N=6 N=5 N=4 N=3 N=2 N=1
3/V595 (4+1) Lo
Feedstock
Lo-BL Hi-BL HI
Feedstock
Single
Grade
3/V595 (3+1) Lo
Feedstock
BL HI
Feedstock
Single
Grade
3/V595/U Lo
Feedstock
Lo-BL MidBL Hi-BL HI
Feedstock
3/V595/U (4) Lo
Feedstock
Lo-BL Hi-BL HI
Feedstock
