High-Resolution IR Camera
User Manual
16
Issue V1.0 (2018-03-20)
Specifications
0E-HDD2MP28
0E-HDD2MP28G
0E-HDDMO2812
0E-HDDM2812G
CAMERA
Image Sensor
1/2.9”Sony CMOS
Signal System
PAL/NTSC
Min. illumination
0.01Lux@(F1.2,AGC ON) ; 0Lux@(IR LED ON)
S/N Ratio
≥50dB
Day & Night
ICR
Shutter Speed
PAL:1/50-1/50000, NTSC:1/60-1/60000
Wide Dynamic Range
dWDR
Digital Noise Reduction
2D
Lens
2.8mm
Motorized 2.8-12mm
FOV
90°
90°-35°
IR LED
18pcs
24pcs
IR Wavelength
850nm
IR Range
20m
40m
OSD Joystick
Support
Up the Coax
Support
Effective Resolution
1920x1080
Frame
PAL:25fps ,NTSC:30fps
VIDEO OUTPUT
Max Distance
75-5 300m
Video Output
AHD/TVI/CVI/CVBS
GENERAL
Power Supply
DC12V±10%
Power Consumption
3.5W(Max)
4W(Max)
Operating Temperature
-25°C ~ 55°C (-13°F ~ 131°F )
Operating Humidity
0% - 85% RH
Ingress Protection
IP66
Material
Aluminium Alloy
