13
Input Video Level
0.5-1.0 V p-p
Maximum Pixel Clock
600MHz
Video Impedance
100ohms
General
Operating Temperature
+32°F to +113°F (0°C to +45°C)
10% to 90%, non-condensing
Storage Temperature
-4°F to +158°F (-20°C to +70°C)
10% to 90%, non-condensing
ESD Protection
Human Body Model:
±8kV (air-gap discharge)/
±4kV (contact discharge)
Power Supply
DC 18V 1A
Power Consumption (Max)
 Transmitter: 13W (When
connect the power adapter to
transmitter to power both
units.)
 Receiver: 12W (When connect
the power adapter to receiver
to power both units.)
Dimensions
136.4mm ×15.2mm × 74.2mm
(5.37'' x 0.60'' x 2.92'') each for
Transmitter/Receiver
Net Weight
0.24kg/0.53lb each for
Transmitter/Receiver
Certification
CE, FCC, RoHS
