wbox 0E-41TP1UN - Specifications

Specifications
Model
0E-41TP1UN
0E-82TP1UN
0E-162TP15UN
Video/Audio
input
IP video input
4-ch
8-ch
16-ch
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Incoming bandwidth
25Mbps
50Mbps
100Mbps
Outgoing bandwidth
80Mbps
Remote connection
32
128
128
Video/Audio
output
Recording resolution
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Frame rate
Main stream: 50 fps (P) / 60 fps (N)
Sub-stream: 50 fps (P) / 60 fps (N)
HDMI/VGA output
1-ch, resolution:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz,
1024 × 768 /60Hz
Audio output
1-ch, RCA (Linear, 1kΩ)
Decoding
Live view / Playback
resolution
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Capability
4-ch@1080P
8-ch@720P, 6-
ch@1080P
16-ch@4CIF, 12-ch@720P, 6-
ch@1080P
Hard disk
SATA
1 SATA interface for 1
HDD
2 SATA interfaces for 2 HDDs
Capacity
Up to 4TB for each disk
External
interface
Network interface
1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interface
USB interface
1 × USB 2.0 and 1 × USB 3.0
2 × USB 2.0 + 1 × USB 3.0
Alarm in/out (Optional)
4 / 1
16 / 4
Serial interface
RS-232 and RS-485
PoE
Interface
4 independent 100
Mbps PoE network
interfaces
8 independent 100
Mbps PoE network
interfaces
16 independent 100 Mbps PoE
network interfaces
Max. Power
50W
120W
200W
Supported standard
AF and AT
Others
Power supply
48V DC
220V AC
Consumption (without
hard disk and PoE)
10W
20W
Working temperature
-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF)
Working humidity
10 % ~ 90 %
Chassis
1U chassis
19-inch rack-mounted
1U chassis
19-inch rack-mounted 1.5U
chassis
Dimensions
(W × D × H)
315 × 230 × 45mm
(12.4"×9.1"×1.8")
445 × 290 × 45mm
(17.5" × 11.4" × 1.8")
445 × 390 ×70 mm ( 17.5"×
15.3" × 2.8")
Weight
(without hard disk)
1 kg (2.2 lb)
4 kg (8.82 lb)
