Weaver Leather Master Tool Cub - Attaching the Hand-Crank Flywheel

4
You may find it easier to transport the Master Tool Cub without the Flywheel
attached. The Flywheel can be easily removed after loosening the Bolts with a
3/16" Allen Wrench. Below are instructions on attaching the Flywheel.
1) Locate the flat sides on the Flywheel Shaft. (Figure 1)
2) Slide the Hand-Crank Flywheel on the Flywheel Shaft, making sure to
line up the Bolts with the flat sides on the Flywheel Shaft. (Figure 2)
3) Tighten the Bolts using the included 3/16" Allen Wrench. (Figure 3)
ATTACHING THE HAND-CRANK FLYWHEEL
Figure 2 Figure 3Figure 1
Hand-Crank Hand-Crank
FlywheelFlywheel
Flywheel Flywheel
ShaftShaft
BoltsBolts
