Webasto DUAL TOP RHA-100 Workshop Manual

2 Technical data Dual Top
202
Table 202: Technical data RHA 101/102
Heater Operation Dual Top RHA 101 Dual Top RHA 102
Type approval
heater:
EMC:
e1 00 0195
e1 03 5000
e1 00 0195
e1 03 5000
Model Air heater with
evaporator burner
and electric heating
device
Air heater with
evaporator burner
and electric heating
device
Heat output
diesel
electric
Control range 1.5 - 6.0 kW
0.6 - 1.2 kW
1.5 - 6.0 kW
1.0 - 2.0 kW
Fuel Diesel, DIN/EN 590 Diesel, DIN/EN 590
Fuel consumption Control range 0.17 - 0.65 l/h 0.17 - 0.65 l/h
Rated voltage 12 V 12 V
Operating voltage range 10.5 - 15 V 10.5 - 15 V
Current input at 12V Summer mode
Winter mode, heat and hot
water
Stand-by
< 1 A
0.5 ~ 7 A
0.001 A
< 1 A
0.5 ~ 7 A
0.001 A
Rated power consumption Control range 15 - 65 W (EN 1646) 15 - 65 W (EN 1646)
Max. ambient temperature:
Heater:
- Operation
- Storage
Control Panel:
- Operation
- Storage
-30 ~ +50 °C
-40 ~ +85 °C
-25 ~ +50 °C
-40 ~ +85 °C
-30 ~ +50 °C
-40 ~ +85 °C
-25 ~ +50 °C
-40 ~ +85 °C
Max. altitude (guaranteed function) 2,200 m 2,200 m
Adjustment range for interior
temperature
Control range +5 ~ +35 °C +5 ~ +35 °C
Delivery rate for hot air (free blowing
without warm-air duct)
Maximum > 200 m
3
/h > 200 m
3
/h
CO
2
in exhaust gas (permitted
function range)
2 kW
6 kW
5.0 ~ 8.0
9.0 ~ 13
5.0 ~ 8.0
9.0 ~ 13
Water capacity 11 l 11 l
Water system pressure max. 3,5 bar max. 3,5 bar
Overpressure valve 4.0 bar 4.0 bar
Pressure water pump, central water
supply
Maximum 2.5 bar 2.5 bar
Heater dimensions Length: 530 ± 2 mm
Width: 352 ± 1 mm
Height: 256 ± 1 mm
Length: 530 ± 2 mm
Width: 352 ± 1 mm
Height: 256 ± 1 mm
Weight (w/o water contents) 21 kg 21 kg
