Ford Transit London
33
NOTE: When working with constant-tension band clamps, always use tools designed for them.
Using slip-joint, tongue-and-groove, or other types of pliers will compromise the integrity of the
clamps. Failure to do so can cause leaks, damaging the vehicle.
Parts required for hose installation:
Item
Number
Part Number Description Quantity
22 5013213A HOSE - REFRIGERANT -6 As needed
51 5011002A FITTING REFRIGERANT 90 -6CONN -6HOSE 1
52 5013071A BAG - TXV PLATE 1
44 5011005B FITTING REFRIGERANT 90 -12TUBE-O -10HOSE 1
49 5011232B SPLICER IN LINE -10HOSE WITH PORT 1
24 5013168A HOSE - REFRIGERANT -10 As needed
54 6233268A BAG - PRESSURE SWITCH 1
27 5012587A HARNESS - T-STAT or LOW PRESSURE SWITCH - 8600mm 1
47 5011030B FITTING REFRIGERANT 45 -10THD TO -10H 1
42 5011029B FITTING REFRIGERANT 45 -08THD -08HOSE 1
23 5013159A HOSE - REFRIGERANT -8 As needed
46 5011231B SPLICER IN LINE -08HOSE WITH PORT 1
43 5011244B SPLICER IN LINE -10HOSE WITH PORT 1
50 5011212B FITTING REFRIGERANT 180 -06THD -06HOSE 1
41 5011028B FITTING REFRIGERANT 45 -06THD -06HOSE 1
45 5011008B FITTING REFRIGERANT 90 -06THD -06HOSE 1
48 5011010B FITTING REFRIGERANT 90 -08THD -08HOSE 1
26 503221A HOSE HEATER 5/8 INCH ID 21M 1
25
5013225A
HOSE HEATER 0.75 ID GATES BLUE STRIPE As needed
73 5011861A CLAMP SPRING BAND 22mm 12
77 5012120A BLEEDER VALVE OD 16mm 1
75 5012117A TEE COOLANT 19-16mm 2
74 5011862A CLAMP SPRING BAND 27mm 4
76 5013547A COUPLER REDUCER 3/4 X 5/8 PLASTIC 1
64 629069011A TEE DRAIN HOSE 12MM OD 1
To Next Page
