F016J10013A UK Page 7
2
Cylinder Mower
Part number
Engine size (cm
3)
Fuel Tank capacity (l)
Rated power [kW/Hp] 3600rpm
Blade width (cm)
Height of cut (mm)
Cuts per metre
Grassbox capacity (l)
Weight (kg)
Max overall width (mm)
Serial Number See rating details on machine
This product is intended for domestic lawn
mowing.
This manual gives instructions on the correct as-
sembly and safe use of your machine. It is im-
portant that you read these instructions care-
fully.
When fully assembled the machine weighs ap-
proximately 38 kg – 41.5 kg. If necessary, obtain
assistance to remove from packaging.
Take care when transporting the mower to the
lawn, as the blades are sharp.
Carefully remove the machine from its packag-
ing and check that you have all the following
items:
– Lawnmower with handle assembly
– Operating instructions
– Machine registration card
– Engine maintenance manual
– Hexagonal wrench
– Grassbox
– Grassbox cradle
When parts are missing or damaged, please
contact your dealer.
1 Throttle lever
2 Red safety latch
3 Cutter control lever
4 Drive control lever
5 Handle top
6 Engine cut-off switch
7 Petrol filler cap
8 Petrol tank
9 Handle bottom
10 Grassbox
11 Choke lever
12 Air cleaner
13 Recoil cord handle
30 Serial No
Not all of the accessories illustrated or described are
included as standard delivery.
Handles
Unfold the handle top 5 and secure with wing
nut 15. Make sure the cables do not become
trapped between the handles.
The handle top is height adjustable. The spin-
dle 16 can be repositioned in desired position I,
II or III .
Use cable clips to attach cables to bottom han-
dle 9 and top handle 5.
Product Specification
Intended Use
Introduction
Delivered Items
Operating Controls
Assembly
A
C14L C17L
C14L C17L
87 87
1.6 1.6
1.6/2.2 1.6/2.2
35 43
9-32 9-32
72 72
32 40
38 41.5
530 605
