ADJUSTINGTHEBLADES
.

Turnthetwolockingbolts(A&B)counter-clockwiseonbothsideplatesofyourmower.

Adjustbothtopadjustmentboltspositionedonbothsidesofyourmower.
Ifthebladesaremakingcontact,turntheadjustmentboltsclockwise,whilerotatingthecuttingreel,
stoppingassoonasthebladelosecontact.
Ifthebladesdidnotcutthepaper,turntheadjustmentboltscounterclockwise,whilerotatingthe
cuttingcylinder,untilthebladesmakecontact.

Whenproperlyadjusted,thecuttingcylinderandbottomstaticbladeshouldbejustshortofmaking
contact.Whenthebladesarecorrectlyadjusted,firmlytightenthelockingboltsonthesideplates,
youpreviouslyloosened.Ifissuesstillpersist,repeatadjustmentsteps.

ADJUSTINGTHECUTTINGHEIGHT
Thismowerhas9cuttingheightsettings,between12-75mm.Movetheheightadjusterhandle/arm
upanddowntheguideforyourchosenheightofcut.

INSTRUCTION MANUAL
Fig.11
Fig.13
Fig.12
Fig.14
Before adjusting the blades, source a 13mm open end spanner(Not supplied).
