ASSEMBLY

Itisrecommendedthatyouweargardeninggloveswhenunpacking,adjusting,assemblingand
maintainingthelawnmower.

Removethemachineandcontentsfromthecarton.Besurethecartonisemptybeforediscarding.

Ifyourequireanyassistancewithregardstothecontentsofthelawnmowercontactus:
Tel:01793333212-Mon–Fri8.00am–5.30pm
Email:customerservice@webblawnmowers.co.uk
(excl.BankHolidays)

STEP1–HANDLE
CAUTION
Thisoperationmustbedoneclosetothecuttingcylinderblade.Westronglyrecommendtheuse
ofthickgardeningglovesonbothhandsandthelawnmowerbodyissecuredtostopthecutting
cylinderbladefromrotating.
• Insertthemiddlehandlesintothetophandle.Lineupholesandinsertboltandtightenwith
wingnut.Ensuretheconcavedsectionofthemiddlehandlesarefacinginwards.
• Slotthelowerhandleoverthepinsonthemainbodyofthemowerandsecurewiththe
suppliedE-Clips.
• Alignthemiddlehandlestothelowerhandles,insertboltandtightenwithwignutsx4.


     
STEP2–GRASSCOLLECTOR
• Thegrasscollectorhastwopositions,dependingontheheightofgrassbeingcut.
• Theuppertorsionbar(Fig.7–a)isidealfortheuppercuttingheightsofthemachine.If
usingthelowerheights,positionusinglowertorsionbar(Fig7–b).


