Webb WER16HP - Page 19

Item No Part No Description Qty
1 B&S 450E Petrol Engine 1
2 QG112-10 Self-Tapping Screw ST6.3x18 2
3 QG112-11 Large Washer 6x18x1.6 2
4 WE113-42 Lock Nut M6/8.8 3
5 QG112-12 Rear Discharge Base A 2
6 QG112-13 Rear Discharge Base B 1
7 QG112-14 Bolt M6x16 3
8 WE113-12 Lock Nut M8/8.8 6
9 QG112-15 Left Rear Bracket 1
10 WE113-34 Square Neck Bolt M8x15/8.8 6
11 WE113-42 Lock Nut M6/8.8 4
12 QG112-16 Bolt M6x12 4
13 QG112-17 Height Adjustment Rod 1
14 WE114-21 Hex Self-Tapping Screws 3/8 16x1ST 3
15 WE70740930590 Deck 1
16 QG112-20 Height Adjustment Board 1
17 QG112-21 Right Rear Bracket 1
18 WE113-25 "O" Ring 11.2x2.65 1
19 WE113-26 Hose Connector Inlet 1
20 WE113-27 Hose Connector Nut M12x1.25 1
21 WE113-28 Cable Stopper 1
WER16HP - Deck Assembly
