Webb WER18HP - Page 25

Item No Part No Description Qty
1 WE70740661590 Deck 1
2 WE113-25 1
3 WE113-26 Hose Connector Inlet 1
4 WE113-27 Hose Connector Nut M12x1.25 1
5 WE113-28 Cable Stopper 1
6 WE113-29 Left Handle Bracket 1
7 WE113-30 Right Handle Bracket 1
8 WE113-31 Hex Bolt M8x14 4
9 WE113-12 Lock Nut M8/8.8 6
10 WE113-33 Height Adjustment Board 1
11 WE113-34 Square Neck Bolt M8x15/8.8 2
12 WE113-35 Rear Drive Right Bracket 1
13 WE113-36 Rear Drive Left Bracket 1
14 WE113-37 Hex Self-tapping screw M6x10 4
15 WE113-38 Height Adjustment Spring 1
16 WE70180270130 Height Adjustment Rod 1
17 WE113-67 R Pin 1.5x25 2
18 QG112-16 Bolt M6x12 2
19 WE113-42 Lock Nut M6/8.8 2
20 WE113-47 Mulch Plug 1
21 B&S 450E Engine 1
O Ring ￠11.2X￠2.65
WER18SP - Deck Assembly
