SPECIFICATIONS
Model WER18HP4 WER18HW4
Product Number 1938323001 1938324001
Working Width 460mm (18”)
Drive Type Hand Push Self-Propelled
Cutting Heights 25-80mm - 8 levels 25-90mm - 8 levels
Height Adjustment Single Lever
Collector Capacity 65L
Deck Steel
Wheel Diameter Front 7” - Rear 8”
Functions Rear Collect - Mulch
Rear Collect - Mulch -
Side Discharge
Engine
Single cylinder, 4-stroke,
air-cooled, OHV (Overhead Valve)
Single cylinder, 4-stroke,
air-cooled, OHV (Overhead Valve)
Engine Displacement 125cc 140cc
Rated Engine Power 1.72kW 1.96kW
Rated Engine Speed 2800rpm
Oil Tank Capacity 0.47L
Fuel Tank Capacity 0.75L 0.8L
Guaranteed Noise Power Level L
WA
95 dB(A)
Emission Sound Pressure Level L
PA
73.5 dB(A) - uncertainty K: 3 dB(A)
Vibration a
hv
:
4.032 m/s
2
uncertainty K: 1.5 m/s
2
4.120 m/s
2
uncertainty K: 1.5 m/s
2
The manufacturer reserves the right to change the product specification and livery according to continued
product improvements.
