Webb WER41SP - Page 19

Item No Part No. Description Qty Item No Part No. Description Qty
1 WE50492 -145 Cutting Deck 1 39 WESL46 -5Z07207 Drive Gear - Left 1
2 WE50441 -01 Cutting Blade 1 40 WESL46 -5Z07208 Drive Gear - Reft 1
3 WE479504 Blade Boss 1 41 WE479285 Pin Φ5*16.5 2
4 WE479502 Blade Bolt 1 42 WE50292 -01 Front Axle Bush 2 5 WE51173 -01 Connecting Bar 1 43 WESL46 -5Z07011 Front Wheel 2
6 WE50651 Height Adjustment Handle 1 44 WESL46 -5Z07012 Rear Wheel 2
7 WE50279 Connecting Bar Spring 1 45 WESL46 -5Z07102 Front Wheel Trim 2
8 WE50280 Height Adjustment Board 1 46 WESL46 -5Z07209 Rear Wheel Trim 2 9 WE50273 -01 Grass Collector Frame 1 47 WE50291 Clip Cpring 2
10 WE50274 -01 Grass Collector 1 48 WE479356 Gearbox Clip 1
11 WE50270 -01 Rear Discharge Cover 1 49 WE50524 Fixed Bush 2
12 WE50271 Rear Discharge Cover Spring 1 50 WE50678 Bush 2 13 WE50272 -01 Rear Discharge Cover Axle 1 51 WE480508 Sanli Engine 1P60F -A 1
14 WE50655 -01 Upper Handle 1 52 WE51309 Nut M8 2
15 WE50656 -01 Lower Handle 1 53 WE479283 Nut M8 2
16 WE50283 -01 Lower Handle Mounting - Left 1 54 WE479265 Washer 8 4
17 WE50284 -01 Lower Handle Mounting - Right 1 55 WE479290 Clip 4 2 18 WE479031 -01 Flash Nut 2 56 WE479273 Pin 2 ×20 2
19 WE479179 Recoil Hook 1 57 WE479263 Nut M5 2
20 WE50416 Bolt M8 ×50 2 58 WE50696 Nut M5 1
21 WE479165 Brake Cable 1 59 WE50294 Bolt M5 ×12 3
22 WESL40 -3T05050 Throttle Cable 1 60 WE479683 Bolt M6 ×12 2
23 WE50647 Drive Cable 1 61 WE50295 Nut M6 2
24 WE200104 Throttle Control 1 62 WE50297 Nut M8 8
25 WE479066 Drive Lever 1 63 WE50698 Bolt M8 ×16 8
26 WE479035 Brake Lever 1 64 WE479317 Flat Washer φ8.5 ×φ18 ×2 2
27 WE479036 Cable Bracket 1 65 WE479282 Bolt M8 ×32 3
28 WE51285 Front A
xle 1 66 WE50300 Washer φ24 ×φ8 ×3 3
29 WE51050 Rear Axle 1 67 WE50630 Nut M6 1
30 WE50491 Rear Axle Bush 2 68 WE479581 Flat Washer φ10.5 ×φ30 ×3 1
31 WE50496 Rear Axle Pplate 2 69 WE479277 Screw ST6 ×14F 8
32 WE51341 Inner Wheel Trim 2 70 WE50695 Screw ST4.8 ×16 2
33 WE51046 Gearbox Assembly 1 71 WE479289 Washer φ12.5 ×φ24 ×0.5 6
34 WE479086 Belt Tension Spring 1 72 WE50476 Woodru Key 4.8 ×6.5 ×16 1
35 WE50648 Belt Cover 1 73 WE479284 Pin 5 ×35 2
36 WE50649 Belt A -660 1 74 WE479322 Pin 4 ×18 2
37 WESL46 -5Z07213 Front Belt Pulley 1 75 WE479271 Spring Washer 12
2
38 WESL46Z -A07115 Rear Belt Pulley 1 76 WE479268 Nut M6 1
77 WE479269 Bolt M6 ×55 1
