Item No
Part No Description Qty Item No
Part No Description Qty Item No
Part No Description Qty
1 WESL46-5Z05020-145 Drive Lever 1 30 WESL42T-01102－145 Front Bumper 1 58 WE50737 Blade Boss 1
2 WESL46-5Z05101－103 Upper Handle 1 31 WEGB/T13575.1-92 Belt A686 1 59 WESL42Z-02101-01 Cutting Clade 1
3 WE479399 Handle Soft Grip 1 32 WE51168 Connecting Bar Spring 1 60 WE50630 Spring Washer 10 1
4 WE479524-145 Brake Lever 1 33 WE479273 Pin 2×20 2 61 WE50810 Blade Bolt 3/8"-24UNF-2A
1
5 WE479498 Bolt M6×40 1 34 WE51269-01 Connecting Bar 1 67 WE492025 Spring Washer 4
6 WE51091 Brake Cable 1 35 WE479275 Flat Washer φ10.5×φ16×1.5
2
68 WESL46-5Z07109 Belt Tension Spring 1
7 WE51089 Drive Cable 1 36 WE479283 Nut M8
2
69 WE50871 Gearbox 1
8 WE479268 Nut M6 4 37 WE479265 Washer 8 4 70 WE50806 Rear Axle 1
9 WE50695 Screw ST4.8×16 3 38 WE50363-122 Rear Wheel Trim 2 71 WE479322 Spring Pin 4×18 2
10 WESL42Z-07125-01 Belt Cover 1 39 WE479051 Stamping Bearing 8 72 WE492042 Enduring Washer φ12.5×φ24×0.5 6
11 WESL42Z-01101－134 Belt Fixed Bracket 1 40 WE122-40 Rear Wheel 210mm 2 73 WE479260 Washer 8 2
12 WE479683 Bolt M6×12 3 41 WE479072-01
Rear Wheel Inner Cover - Right 1 74 WE50409-01 Height Adjustment Bar 1
13 WE479705 Nut M6 1 42 WE479244-01 Rear Wheel Inner Cover - Left 1 75 WE479258 Bolt M8×25
1
14 WESL42Z-04101-01 Grass Collector Rear Flap 1 43 WE4
79285 Pin φ5×16.5 2 76 WE479356 Gearbox Clip 1
15 WESL42Z-04109 Grass Collector Rear Flap Axle 1 44 WE479271 Spring Washer 12 2 77 WE479277 Screw ST6×14F 8
16 WE50444 Clip 6 2 45 WE479079 Drive Gear - Right 1 78 WE479085 Rear Axle Plate - Right 1
17 WESL46-5Z04107 Grass Collector Rear Flap Spring 1 46 WE479078 Drive Gear - Left 1 79 WE50524-01 Fixed Plate 2
18 WE50736-103 Lower Handle 1 47 WESL42Z-04022-01 Grass Collector Frame 1 80 WE479084 Rear Axle Plate - Left 1
19 WE120-25 Quick release handle 2 48 WE51323 Grass Collector Bag 1 81 WE50618 Height Adjustment board 1
20 WE479581 Flat Washer φ10.5×φ30×3 3 49 WE479328 Bolt M8×35 3 82 WE50518-01 Cable Clip 1
21 WE479179 Recoil Hook 1 50 WE50804 Front Axle 1 83 WESL46Z-A07115-01 Rear Belt Pulley 1
22 WE479304 Nut M8 10 51 WESL42T-07108-01 Front Axle Bush 2 84 WE479083 Rear Axle Bush 2
24 WE50443 Bolt M8×18 8 52 WESL42T-07306 Clip Spring 2 85 WE479036-01 Cable Clip 1
25 WESL42Z-04103-01 Lower Handle Mounting - Right 1 53 WE50361-122 Front Wheel Trim 2 86 WE51324 Engine BS450E 1
26 WESL42Z-04102-01 Lower Handle Mounting - Left 1 54 WE479045-01 Front Wheel Inner Cover 2 87 WE479210 Washer 1
27 WESL46-5Z05105 Strengthen Plate 2 55 WE121-36 Front Wheel 175mm 2 88 WE479283 Nut M8 3
28 WE50807 Rivet 5×12 2 56 WE479287 Woodruff Key 4×6.5×16 1 89
WE50300 Washer φ24×φ8×3 3
29 WE51000-145 Cutting Deck 1 57 WESL46-5ZB07213BS Front Belt Pulley 1 90 WE50766 Spring Pin 5×40 1
