Webb WER42SP - Page 23

Item No.
Part No.
Description
Qty
Item No.
Part No.
Description
Qty
Item No.
Part No.
Description
Qty
1
WE50332-145
Cutting Deck
1
34
WE50763
Brake Cable
1
66
SA50630
Spring Washer 10
1
2
WE50391-01
Front Cover
1
35
WE479036-01
Cable Bracket
1
67
SA479258
Bolt M8×25
1
3
WE479092
Side Discharge Fixed Plate
1
36
WE120-36
Front 200mm Wheel Assembly
2
68
SA479257
Nut M8
5
4
WE479093-01
Side Discharge Axle
1
37
WE479051
Wheel Bearing
8
69
SA479260
Washer 8
2
5
WE50412-01
Side Discharge Cover
1
38
WE50362-122
Front Wheel Trim
2
70
SA479273
Pin 2×20
2
6
WE50413-01
Side Discharge Chute
1
39
WE479050-01
Front Inner Wheel Cover
2
71
SA492071
Flat Washer φ10×φ16×1.0
2
7
WE50421
Side Discharge Spring
1
40
WE479122-01
Front Axle Bush - Upper
2
72
SA479210
Washer
1
8
WE50422
Cutting Blade
1
41
WE479123-01
Front Axle Bush - Lower
2
73
SA479268
Nut M6
1
9
WE50475
Blade Bolt 3/8"-24UNF-2A
1
42
WE479124
Front Axle
1
74
SA479498
Bolt M6×40
1
10
WE50521
Blade Boss
1
43
WE120-43
Rear 280mm Wheel Assembly
2
75
SA479279
Bolt M6×65
4
11
WE50335-01
Mulch Plug
1
44
WE50365-122
Rear Wheel Trim
2
76
SA479280
Nut M6
4
12
WE50358-01
Height Adjustment Handle
1
45
WE479177-01
Rear Wheel Dust Cover - Right
1
77
SA492025
Washer
4
13
WE492106-01
Connecting Bar
1
46
WE479246-01
Rear Wheel Dust Cover - Left
1
78
SA479271
Spring Washer 12
2
14
WE50336
Height Adjustment Board
1
47
WE492080
Rear Axle
1
79
SA479285
Pin φ5×16.5
2
15
WE479103
Front Axle Spring
2
48
WE479078
Drive Gear - Left
1
80
SA479284
Spring Pin 5×35
1
16
WE50436-01
Rear Discharge Cover
1
49
WE479079
Drive Gear - Right
1
81
SA479322
Spring Pin 4×18
2
17
WE50437-01
Grass Collector Frame
1
50
WE50340
Gearbox
1
82
SA479328
Bolt M8×35
1
18
WE51327
Grass Collector
1
51
WE479356
Gearbox Clip
1
83
SA479283
Nut M8
7
19
WE106-59
Rear Discharge Cover Axle
1
52
WE479082-01
Rear Axle Bush
2
84
SA479265
Washer 8
6
20
WE479026
Rear Discharge Spring A
1
53
WE479084
Rear Axle Plate - Left
1
85
SA479295
Spring washer 8
2
21
WE50337-01
Lower Handle Mounting - Left
1
54
WE479085
Rear Axle Plate - Right
1
86
SA479304
Nut M8
6
22
WE50338-01
Lower Handle Mounting - Right
1
55
WE492042
Washer φ12.5×φ24×0.5
6
87
SA50443
Bolt M8×18
4
23
WE50440-103
Upper Handle
1
56
WE50739
Belt Tension Spring
1
88
SA50573
Bolt M8×25
2
24
WE50410-103
Lower Handle
1
57
WE50415-01
Belt Cover
1
89
SA479317
Flat Washer φ8.5×φ18×2
2
25
WE120-25
Quick Release Handle Assembly
2
58
WE50474
Belt - XPZ850
1
90
SA50698
Bolt M8×16
2
26
WE51072-01
Lower Handle Fixing Knob
2
59
WE50524-01
Fixed Bracket
2
91
SA50444
Clip 6
2
27
WE479179
Recoil Hook
1
60
WE479204-01
Belt Pulley
1
92
SA5059
4
Bolt M5×12
2
28
WE50339
Lower Handle Mounting Plate
2
61
WE50402-01
Front Belt Pulley
1
93
SA50696
Nut M5
2
29
WE50518-01
Cable Clip
1
62
WE51326
Engine BS625E
1
94
SA479581
Flat Washer φ10.5×φ30×3
3
30
WE479399
Handle Grip
1
63
WE479005
Engine Bolt
2
95
SA479287
Woodruff Key 4×6.5×16
1
31
WE50344-145
Brake Lever
1
64
SA479277
Screw ST6×14F
8
96
SA479267
Nut M6
2
32
WE50583-145
Drive Lever
1
65
SA479288
Screw ST4×15F
7
97
SA479290
Circlip 4
1
33
WE50503
Drive Cable
1
98
SA479291
Bolt M6×16
2
