Webb WER42SP - Page 6

2. UPPER HANDLE BAR ASSEMBLY
4. ATTACHING THE DRIVE CABLE
5. FIT THE CABLE CLIPS
5. FIT THE CABLE CLIPS
2a 2b
7a
7b
4. Aaching the Drive Cable
4a.
Pull the drive lever out of the
left side hole and lower
towards the mower.
4b.
the mower handle
5. Fit the Cable Clips
Push the cable clips into place.
Parts required:
2 x Quick Release Handles
2 x 8 cm length Bolts
1 x Spring Cord Guide
6. Locate the Starter Cord
Pull the stater cord upto the
spring. holding the cord at the
lower side of the spring rotate
the string clockwise around
the spring.
7. Aach the Grass Catcher
7a.
with one hand.
7b.
Lower the Grass catcher
hooks onto bar, left and right.
4a 4b
5
INSTRUCTION MANUAL
Remove and ensure you have all the parts
required for assembly (see page 2 for reference)
Parts required:
4 x Round cap nuts
and 4 cm length bolts
1. LOWER HANDLE BAR ASSEMBLY
3. ATTACHING THE SAFETY (OPC) CABLE
6. LOCATE THE STARTER CORD
1.
1. Lower Handle Bar Assembly
attach lower handle bar bolts.
take the weight of the handle
2. Upper Handle Bar Assembly
Spring cord Guide and bolt.
6
3a
3b
3. Aaching the Transmission Cable
and bolt.
3a.
Pull the brake lever out of the right
side hole, tilt forward and lower towards
the mower.
3b.
Insert the end of the cable into the
hole in the lever and replace the lever
back into hole of the handle.
INSTRUCTION MANUAL INSTRUCTION MANUAL
