Webb WER46SP - Page 17

WER46SP
Product No.
193862001
It
em No
Part No Description Qty Item No
Part No Description Qty Item No
Part No Description Qty
1 WE51343-145 Cung Deck 1 27 WE479038-01
Throle Control
1 54 WE479823 Sanli Engine 1P64F-A 1
2 WESL46-5Z01102
−
145 Front Fender 1 28 WE479039-01 1 55 WESL46-5Z05105 Strengthen Plate 2
3
WE479502
Bolt 3/8"-24UNF-2A
1
29 WE479040-01 1 56 WE51309 Nut M8 2
4
WESL46-5Z02101
−
P
Cung Blade 1 30 WESL46-5Z07011 Front Wheel 2 57 WE479283 Nut M8 2
5 WESL46-5Z02105 Blade Boss 1 31 WESL46Z-C07102
−
122 Front Wheel Trim 2 58 WE479265 Washer 8 4
6 WE50994 Height Adjustment Board 1 32 WESL46Z-
5Z07012 Rear Wheel 2 59 WE50807 Rivet 5×12 2
7 WE51321 Connecng Bar 1 33 WESL46-5Z07102
−
122 Rear Wheel Trim 2 60 WE479273 Pin 2×20 2
8 WE50278 Height Adjustment
Handle 1 34 WE51341 Rear Wheel Inner Trim 2 61 WE479275 Flat Washer φ10.5×φ16×1.5
2
9 WESL42T-03103 Connecng Bar Spring 1 35 WE50678 Bush 2 62 WE50444 Clip 6 2
10 WE51014 Grass Collector Frame 1 36 WESL46-5Z07125 Belt Cover 1 63 WE479304
Nut M8
8
11 WE51015 Grass Collector 1 37 WESL46-5Z07020 Front Axle 1 64 WE50443
Bolt M8×18 8
12 WESL46-5T04102 Grass Collector Rear Flap 1 38 WESL42T-07306 Clip Spring 2 65 WE50476 Woodruff Key 4.8×6.5×16 1
13 WESL46-5Z04107 Grass Collector Rear Flap Spring 1 39 WESL42T-07108 Front Axle Bush 2 66 WE479268
Nut M6
3
14 WESL46-5Z04109 Grass Collector Rear Flap Axle 1 40 WE51320 Rear Axle 1 67 WE50767 Bolt M6×52 1
15 WESL46-5Z05101
−
01 Upper Handle 1 41 WE51322 Gearbox 1 68 WE50695 Screw ST4.8×16 2
16 WESL46-5Z05102
−
01 Lower Handle 2 42 WESL46Z-A07115 Rear Belt Pulley 1 69 WE4792
71 Spring Washer 12 2
17 WE479080 Lower Handle Rubber Cap 2 43 WEGB/T13575.1-92 Belt A737 1 70 WE479282 Bolt M8×32 3 18 WESL46-5Z04102 Lower Handle Mounng - Le 1 44 WESL46-5Z07109 Belt Tension Spring 1 71 WE50300 Washer φ24×φ8×3 3
19 WESL46-5Z04103 Lower Handle Mounng - Right 1 45 WESL46Z-A07207 Drive Gear - Le 1 72 WE50630 Spring Washer 10 1 20 WE51072-01 Flash Nut 4 46 WESL46Z-A07208 Drive Gear - Right 1 73 WE50445 Flat Washer φ10.5×φ30×3 1
21 WESL46-5Z06104 Recoil Hook 1 47 WESL46-
5Z07213 Front Belt Pulley 1 74 WE50766 Spring Pin 5×40 1
22 WESL40T05110 Bolt M8×45 2 48 WE479356 Gearbox Clip 1 75 WE479270 Bolt M6×30 1
23 WE479524-01 Brake Lever 1 49 WE50491 Rear Axle Bush 2 76 WE479317 Flat Washer φ8.5×φ18×2 2
24 WESL46-5Z05020-01 Drive Lever 1 50 WE50524-01 Fixed Bracket 2 77 WE479322 Spring Pin 4×18 2 25 WESL46-5Z05030
−
TY Drive & Brake Cable 1 51 WE479084 Rear Axle Plate - Le 1 78 WE50327 Bolt M6×16 2
26 WESL40T05050 Throle Cable 1 52 WE479085 Re
ar Axle Plate - Re 1 79 WE50295
Nut M6
2
53 WE492042 Enduring Washer φ12.5×φ24×0.5 6 80 WE479683 Bolt M6×12 2
81 WE479285 Key φ5×16.5 2
82 WE479277 Screw ST6×14F 8
