Side Burner Maintenance

몇WARNING: All gas controls and supply valves should

be in the OFF position.

Check igniter: Remove side burner cover. To remove side

burner cover, remove control knob and screws that hold

cover to bottom. Figure 14. Make sure wire is connected

between igniter and electrode. Check that igniter lock nut

is tight. Figure 15.

Note - If the igniter works loose, carefully tighten the

igniter lock nut with an adjustable wrench or pliers.

Adjust igniter electrode. Gap should be 1/8 to 3/16 inch

from tip of electrode to burner. Figure 16. Spark should be

a white/blue color, not yellow.

Figure 14

Figure 15

Figure 16

Venturi/Burner

Electrode

Igniter wire

1/8 to 3/16

inch gap

Igniter
