Weber Performer Assembly Guide

WWW.WEBER.COM
3
EXPLODED VIEW LIST
1. Lid Handle Assembly
2. Lid
3. Hinged Cooking Grate
4. Charcoal Grate
5. ONE-TOUCH
Cleaning System
6. TUCK-AWAY Lid Holder &
Lower Support Assembly
7. Ash Catcher Ring
8. Ash Catcher Handle
9. High-Capacity Ash Catcher
10. Axle
11. Leg Frame Bracket
12. Wheel
13. Hub Cap
14. Wheel Cover
15. Leg Frame Bracket Clamp
16. Bottom Rack
17. Lid Damper Assembly
18. Thermometer Assembly
19. Bowl
20. Fold-Down Assembly
21. Fold-Down Table
22. Tool Holder
23. Leg Frame
24. Caster Insert
25. Locking Caster

Weber Performer Specifications

General

Lid	Yes
Form factor	Cart
Product color	Black
Housing material	Steel
Top surface type	Grate
Built-in capability	-
Cooking surface shape	Round
Type	Barbecue
Heat source	Charcoal (fuel)
Total power	- W
Adjustable thermostat	No
Cooking surface diameter	570 mm
Number of wheels	4 wheel(s)

Weight and Dimensions

Depth	737 mm
Width	1067 mm
Height	1105 mm
