Signal Booster Specifications
Drive 4G-M
Product Number U470008
Model Number 460008 460021
FCC ID PWO460008 PWO460021
IC 4726A-460008 4726A-460021
Connectors SMA
Antenna Impedance 50 Ohms
Frequency 699-746 MHz, 746-787 MHz, 824-894 MHz, 1850-1990 MHz, 1710-1755 / 2110-2155 MHz
Passband Gain (typical)
700 MHz Band 12/17
45.8
700 MHz Band 13
46.8
800 MHz
46.8
1700/2100 MHz
45.2
1900 MHz
44.6
20 dB Bandwidth (MHz)
700 MHz Band 12/17 700 MHz Band 13 800 MHz 1700/2100 MHz 1900 MHz
Typical
Maximum
30.6
35.2
31.0
35.2
37.9
39.9
79.2
79.8
77.3
83.2
Power output for single cell
phone (Uplink) dBm
700 MHz Band 12/17 700 MHz Band 13 800 MHz 1700/2100 MHz 1900 MHz
21.84 21.35 20.4 18.3 21.43
Power output for single cell
phone (Downlink) dBm
700 MHz Band 12/17 700 MHz Band 13 800 MHz 1700/2100 MHz 1900 MHz
2.87 2.79 2.8 2.0 1.92
Power output for multiple
received channels
(Uplink) dBm
No. Tones
Maximum Power
700 MHz Band 12/17 700 MHz Band 13 800 MHz 1700/2100 MHz 1900 MHz
2 22.4 20.9 19.9 19.8 21.9
3 18.8 17.4 16.4 16.3 18.3
4 16.3 14.9 13.9 13.8 15.8
5 14.4 13 12 11.8 13.9
6 12.8 11.4 10.4 10.2 12.3
Power output for multiple
received channels
(Downlinklink) dBm
Maximum Power
No. Tones 700 MHz Band 12/17 700 MHz Band 13 800 MHz 1700/2100 MHz 1900 MHz
2 4.8 5.6 5.4 6.3 4.5
3 1.3 2.1 1.9 2.8 0.9
4 -1.2 -0.4 -0.6 0.3 -1.6
5 -3.2 -2.4 -2.6 -1.6 -3.5
6 -4.7 -4.0 -4.2 -3.2 -5.1
Noise Figure 5 dB nominal
Isolation > 90 dB
Power Requirements
110-240 V AC, 50-60 Hz, 20 W
Each Signal Booster is individually tested and factory set to ensure FCC compliance. The Signal Booster cannot be adjusted without factory reprogramming or
disabling the hardware. The Signal Booster will amplify, but not alter incoming and outgoing signals in order to increase coverage of authorized frequency bands
only. If the Signal Booster is not in use for five minutes, it will reduce gain until a signal is detected. If a detected signal is too high in a frequency band, or if the Signal
Booster detects an osc llation, the Signal Booster will automatically turn the power off on that band. For a detected oscillation the Signal Booster will automatica ly
resume normal operation after a minimum of 1 minute. After 5 (five) such automatic restarts, any problematic bands are permanently shut off until the Signal Booster
has been manually restarted by momentarily removing power from the Signal Booster. Noise power, gain, and linearity are maintained by the Signal Booster’s
microprocessor.
The Manufacturer’s rated output power of this equipment is for single carrier operation. For situations when multiple carrier signals are present, the rating would have
to be reduced by 3.5 dB, especially where the output signal is re-radiated and can cause interference to adjacent band users. This power reduction is to be by means
of input power or gain reduction and not by an attenuator at the output of the device.
The term “IC” before the radio cert fication number only signifies that Industry Canada technical specifications were met.
Safety Guidelines
WARNING The inside panel and dome antennas must have 6’ of separation distance from all active users,
and the low profile antennas must have 18” of separation distance from all active users.
WARNING Connecting the Signal Booster directly to the cell phone with use of an adapter will damage the
cell phone.
WARNING Use only the power supply provided in this package. Use of a non-weBoost product may
damage your equipment.
WARNING The Signal Booster unit is designed for use in an indoor, temperature-controlled environment
(less than 150 degrees Fahrenheit). It is not intended for use in attics, vehicles or similar locations
subject to temperatures in excess of that range.
WARNING The Outside Antenna must be installed no higher than 10 meters (32’9”) above ground.
RF SAFETY WARNING Any antenna used with this device must be located at least 8 inches from all persons.
This device complies with Part 15 of FCC rules. Operation is subject to two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not
expressly approved by weBoost could void the authority to operate this equipment.
BEFORE USE, you MUST REGISTER THIS DEVICE wi h your wireless provider and have your
provider’s consent. Most wireless providers consent to he use of signal boosters. Some providers
may not consent to the use of this device on their network. If you are unsure, contact your provider.
You MUST operate this device wi h approved antennas and cables as specified by the manufacturer.
Antennas MUST be installed at least 20 cm (8 inches) from any person.
You MUST cease operating this device immediately if requested by the FCC or a licensed wireless
service provider.
WARNING. E911 location information may not be provided or may be inaccurate for calls served by
using this device.
This is a CONSUMER device.
Trucker antenna w/13.5’ RG58
• 311119
• 311133
NMO Antenna’s w/ RG174
Kit 311104-17410
• 800/1900 NMO antenna
• 10’ RG174 cable
Kit 311112-17410
• 800/1900 NMO antenna
• 10’ RG174 cable
Kit 314203-17410
• 800/900/1900 NMO antenna
• 10’ RG174 cable
Marine Antenna’s
Kit 311130-5810
• Marine Antenna
• 10’ RG58 cable
Glass Mount w/14’ RG58 cable
• 311102
• 311114 ( Mini Glass Mount)
NMO Antenna’s w/ RG58
Kit 311104-5810
• 800/1900 NMO antenna
• 10’ RG58 cable
Kit 311112-5810
• 800/1900 NMO antenna
• 10’ RG58 cable
Kit 314203-5810
• 800/900/1900 NMO antenna
• 10’ RG58 cable
Inside Antenna
Slim Low Profile
301152 - w/ 10’ RG174
Low Profile
311106 - w/ 10’ RG58
